Icron USB 3.0 Active Extension Cable

I-USB3-3001-15-AU

Icron

Take advantage of USB 3.0's blazing 5Gbps speeds extended 15 meters over active copper cabling. This rugged SuperSpeed cable offers flexibility in extending USB 3.0 devices in commercial and industrial locations such as machine vision cameras, security cameras, and storage drives.

Description
Specification
Downloads
Videos

*** Does NOT support USB 1.1 and USB 2.0 ***

Key features include:

    USB 3.0 extension for 15m
    Supports USB 3.0 throughputs up to 5Gbps
    Bus powered from host computer, no external power supply needed
    USB 3.0 device port provides 5V, 900mA power
    Second USB 3.0 power connector for use if additional power is required
    Locking USB connector
    Slots on device port for convenient cable tie mounting
    Rugged grade cabling
    Status LED at device port with power, enumeration and over-current indication

Works with AIA USB3 Vision™ compliant devices Includes the ExtremeUSB® suite of features:
         Transparent USB extension
         True plug and play; no software drivers required

Works with all major operating systems:
         Windows®, Mac OS X®, and Linux®

RANGE
Active Copper Cable:	15m (49.21 ft)
SPEEDS
USB 3.0:	Up to 5Gbps (Not backward compatible with USB 2.0/1.1)
PHYSICAL
USB Connector on Device Side:	1 x USB 3.0 Type A Locking Receptacle
USB Connectors on Host Side:	1 x USB 3.0 Type A Host Connector 1 x USB 3.0 Type A Power Connector (required for devices drawing more than 2.5W)
Cable Diameter:	6.9mm (0.27")
Jacket Material:	PVC
Bend Radius:	28mm (1.10")
Mounting Slots on Device Side:	Slots for Cable Tie
POWER
Power Source:	Bus Power
Available Current:	5V, 900mA
ENVIRONMENTAL
Operating Temperature:	0°C to 50°C (32°F to 122°F)
Storage Temperature:	-20°C to 70°C (-4°F to 170°F)
Operating Humidity:	20% to 80% relative humidity, non-condensing
Storage Humidity:	10% to 90% relative humidity, non-condensing
