The SB-5688Kp is based on HDMI standards and supports full resolution HDMI video with (7) embedded EDID. High Definition Digital signals can be selected and distributed to any of the (8) Inputs to the (8)+(1) preview outputs. The switcher is certified as being fully CEC and HDCP 1.3 compliant with HDMI 1.4a, 4K2K@30Hz, DVI 1.0, 3D formats and a wide frequency range of 25MHz ~ 340MHz so there is no signal degradation. Full HD supports UXGA/WUXGA/DVI 1920x1200 resolutions to any HD display. The EDID management can be selected between (7) different modes. Control is provided via front panel push buttons, IR remote, RS-232 or TCP/IP (not a web-browser). A RS-232 Windows GUI interface is provided for matrix routing control (Windows only).
FEATURES
(8) HDMI source devices matrix switched to (8) HDMI+ (1) preview output destinations
HDMI digital video w/ embedded HDCP and DVI formats and CEC/HDCP 1.3 compliant
Worldwide control EDID modes for HDMI full 4K2K (24/30Hz) HD video resolutions
Wide frequency range of 25MHz ~ 340MHz, Support HDMI 4K2K, 1.4a 3D formats
Wide range of HD resolutions from PC XGA to WUXGA 1920x1200 and HDTV/DTV HDMI resolutions 480i/480p, 576i/576p, 720p, 1080i/p & 4K2K (24/30Hz)
Compatible with all HDMI source devices, PC monitors, Plasma HD displayd, HDTV and audio receivers or audio amplifiers
Digital video TMDS formats resolutions up to 4K2K with Deep color 36bit
Using the build-in booster, each HDMI Output port is capable of driving cable lengths for 1080p up to 98 ft (30M) & 4K2K up to 66 ft (20M)
Digital Audio Support: Dolby TrueHD, Dolby Digital, Dolby Digital Plug/ex, DTS, DTS-HD, DTS-HD Master, DTS-EX PCM, PCM2, LPCM2
Various User Interface control:
Windows based GUI control via RS-232 interface
Front panel push buttons
IR wireless remote control
Ethernet switch control
Third party RS-232 control (via simple ASCII)
Supports world wide (9) control function keys: Full function front panel controls: ARC / AUX / ALL / OFF / EDID / LOCK / RECALL / MEMORY / ENTER
Supports (7) world wide control function keys:
Full function front panel controls: ALL / OFF / EDID / LOCK / RECALL / MEMORY / ENTER
Supports EDID Modes:
a. Embedded EDID Modes: FSS / H24-3D / H24-3D-M / H36-3D / H36-3D-M / 4K2K-3D / DVI-D 1920x1200-60Hz
b. External Modes: Learning mode-1 (Single Learning) & Learning mode-2 (Multiple Learning)
Automatic scanning input & output status via LCM show on front panel
Supports IR Remote and IR Extender with distance up to ~984 ft (300M) Maximum
Supports Universal power adaptor AC100V~AC240V, 50/60Hz
